List By Model » ST-EBS9F 20" Fat Folding Electric Bike 500W Folding Electric Bike Fat Tire Ebike E Power Bicycle
500W Folding Electric Bike Fat Tire Ebike E Power Bicycle
  • EU Europe Warehouse Fat Tire Folding 500W 36V Share Electric Bike Fatbike Ebike Power E Bicycle For Adult
  • EU Europe Warehouse Fat Tire Folding 500W 36V Share Electric Bike Fatbike Ebike Power E Bicycle For Adult
  • EU Europe Warehouse Fat Tire Folding 500W 36V Share Electric Bike Fatbike Ebike Power E Bicycle For Adult
  • EU Europe Warehouse Fat Tire Folding 500W 36V Share Electric Bike Fatbike Ebike Power E Bicycle For Adult
  • EU Europe Warehouse Fat Tire Folding 500W 36V Share Electric Bike Fatbike Ebike Power E Bicycle For Adult
  • EU Europe Warehouse Fat Tire Folding 500W 36V Share Electric Bike Fatbike Ebike Power E Bicycle For Adult
  • 500W Folding Electric Bike Fat Tire Ebike E Power Bicycle

    Wattage: 500w
    Voltage: 48V
    Power Supply: Lithium Battery
    Wheel Size: 20X4.0 Snow Fat Bike Tyre
    Motor: Brushless
    Certification: CE EEC
    Frame Material: Aluminum Alloy, Aluminum Alloy
    Foldable: Yes
    Max Speed: 25Km/h(EU),32Km/h(USA)
    Range per Power: 31 - 60 km
    • Description

    500W Folding Electric Bike Fat Tire Ebike E Power Bicycle

    EU Europe Warehouse Fat Tire Folding 48V 500W Cruiser Electric Bike Fatbike Ebike Power E Bicycle For Adult For Sale UK Australia NZ

    Secutronic – China Manufacturer – 500W Folding Electric Bike

    Brief Introduction – 500W Folding Electric Bike

    What is the best wattage for an e-bike?

    The purchase of an electric bicycle not only requires choosing the right type for the use that is going to be given to it, but also the power that we are going to require from its motor due to the type of route or the physical condition and weight of the cyclist.

    The electric bike market offers a wide variety of models and types designed for different uses and different users. Once we are clear about the type of bicycle we want, it is time to choose its components.

    Among them it is possible to choose the power of the motor , which can be configured in a wide range of levels. From the lowest, which usually reach 250 W (0.3 hp) to electric bicycles of 1.5 kW (2 hp), which even exceed some electric motorcycles.

    The different standards that exist to measure the power of electric motors mean that those that theoretically offer the same power can actually have quite different levels.

    In addition, the laws that limit the power of the motor of the electric bicycle to qualify it as such, as is the case of pedelecs in Europe, also known as EPAC (Electronically Power Assisted Cycles), force many manufacturers to electronically limit the power of the engines.

    So, for example, Bosch mid-drive motors , which sit on the bottom bracket, are rated at 250W when in reality they can reach 500W.

    The standard power for an Electric Bike: 250W

    The 250 Watt is the standard power of electric bicycles , since it is the limitation imposed by the European Union to not require homologation, registration, or insurance for its circulation. There are more than 200 models with this power on the market, which are suitable for flat routes, without excessive slopes. In this case, the motors located on the bottom bracket are more appropriate than those located on the rear wheel hub since they allow the classic chain and pinion transmission to be implemented, which facilitates assisted pedaling.

    In any case, this power is enough to move through more or less flat areas . Great accelerations are not achieved but it must be taken into account that the natural pedaling of a person generates less than 250W.

    The speed that these bikes can reach is usually limited to 25 km/h, once again, to comply with pedelec regulations. From that speed, the motor will no longer assist pedalling.

    350W to 500W

    Despite exceeding the limits established by legislation, the market offers much more powerful electric bicycles, which can be used in private facilities or in off-road mountain areas.

    In this power range, the fundamental difference compared to 250W bikes is acceleration , much more noticeable if the cyclist is also light. In addition, the climbs will be somewhat easier to negotiate, although the ease of reaching the top will depend on the slope and the weight of the cyclist, so in some cases there will be no difference with 250 W bikes. Keep in mind that 500W may be the minimum power to exceed 20 MPH speed.

    750W to 1,000W

    From this level of power, the performance of electric bicycles soars in terms of acceleration and speed , in addition to beginning to offer acceptable performance on climbs, regardless of the weight of the cyclist, especially if the power is close to 1 kW.

    The speed that can be achieved with them exceeds 45 km/h , even at the lowest levels of this range, with 750 W of power.

    Take reference to Secutronic Electric Mountain Bike 48V1000W 750W Ebike 48V 750 Watt

    1,500 watts

    With this power, electric bicycles begin to be confused with light electric motorcycles . Its acceleration, speed and climb capabilities are independent of the rider’s weight. In any case, they are capable of overcoming the difficulties that the terrain imposes on them. The only limitation they may have is that the slope is so high that they are unable to achieve traction and skid on the ground.

    Is a 500W ebike enough?

    If what you want is a bicycle to circulate around the city, commute to work or university and do simple routes without steep inclines, the best thing is to get a legal 250W electric bike , which will practically cover all your needs.

    The big difference between 250w and 500w is the ability to go uphill. In short, if you have a 500 watt motor, climbing hills will be a little easier than on a 250W because it will have more power.

    From this power, the choice of power is a personal decision , in which the use that is going to be given comes into play, the type of terrain that you want to overcome and the economic outlay that can be achieved.

    How fast does a 500W electric bike go?

    Pedal-assist bicycles have a maximum power 250W motor, as restricted by European regulations, and only have higher power motors, generally 350 or 500W, those models that allow reaching up to 45 km/h, which must be registered as mopeds.

    Generally, the power of the motor gives us an idea of ​​the speed that the bicycle can give us, and logically of its consumption. Thus, normally a bicycle with a 500W motor will have the advantage of being able to assist the cyclist up to higher speeds (45km/h).

    AdmitJet 500W Electric Bike 20 inch Product:

    Description:

    【POWERFUL PERFORMANCE】: Powered by a high torque 500W motor and 48V Lithium ion battery inside the frame, this fat tire electric bike can travel up to 30 miles at 20 MPH. The upgrade LCD display monitor can display battery level, speed, travel distance and PAS level.

    【FOLDING EBIKE 】: The aluminum alloy frame is folded and easy to carry or store in the car trunk or garage. Riders can easily adjust the seat to find the perfect riding position for the most comfortable pedaling.

    【FAT TIRE】: 20 x 4.0 inch off road fat tires provide traction, grip, and shock absorption that outclasses standard city bike tires. It allows you to be able to ride in any conditions that you may have to face, such as mountain, snow, sandy beaches, muddy roads and other complex road situation.

    【7 SPEED GEAR】: Dual disc brakes and Shimano 7-speed gearing, it’s everything you need to follow any route you choose. The Shimano 7-Speed System allows for optimized speeds, with or without pedal assist activated.

    【SHOCK ABSORBER】: Disc brakes also do not wear out your tires and last much longer.

    【OFF ROAD BIKE】: Superbly sturdy and versatile, this folding e bike is designed for everyone with spirit for fun and outdoors. Buy with confidence. Please feel free to contact us if you have any questions.

    Get Noticed with Low Profile Frame and Fat 20-inch tire which will get you attention when you ride in an urban or off-road environment in various rainy, snowy, mountain and road conditions.

    【ELECTRIC MOTOR】BAFANG 500W, 48V 10Ah Rear Drive Electric Motor. Perfectly balanced, smooth and powerful the motor operates in virtual silence.

    【MAX SPEED】: 20 MPH (32 km/h).

    The ebike drives you at speeds up to 32 km/h and gives you a worry-free range of travel of approximately 60 km per charge on pedal assisted mode. That is more than enough for a complete day of touring. Unlike other electric bikes, which can take up to half a day to charge, the bike is equipped with smart lithium battery charger for a quick 5-6 hours that will give you all the battery power you need for a full charge.

    Handle bar power indicator will help to see your battery’s depletion level.

    Ride in full throttle (no pedaling required) or use 7-speed Smart Pedal Assist for effortless riding experience.

    Folding Electric Bike has low profile frame which makes it easy to get on and off the bike for any rider.

    【QUICK RELEASE】:

    (1) mid-frame folding joint on a spring and Quick Release front wheel allow for easy transporting to your favorite biking destination.

    The bike adopts ultra-lightweight yet strong and durable aluminum alloy frame; high carbon steel suspension fork; anti-rust and anti-exposure mate surface coating.

    (2) Handle bar stem can be folded down instantly. Handle bar can also be adjusted and extended with Quick Release.

    (3) lever upto 5-Inch in height for tall riders’ comfort. Handle bar can be rotated around its axis by another Quick Release.

    (4) lever to suit riders of different height. Seat now can be lifted to reach-in-and-grab the battery.

    (5) Lithium-Ion battery is easily removable by simply lifting up the seat by a Quick Release

    (6) Seat post can be extended in height by a Quick Release

    (7) lever upto extra 8-Inches in height.

    Seat is extra cushy for absolute comfort. Both pedals fold in for better transport.

    Includes LED front light, front and back wheel reflectors, bell, adjustable kick stand.

    【APPLICATION】:

    The Fat tire e bike can take you on to the beach or gravel road, it insures that you do not feel all the bumps and imperfection in the road as with regular tire, also will not allow you to sink in sandy conditions. 20 Inch wheels are made of aluminum alloy and Kenda anti-slip, wear resistant thick tire, suitable for various rainy, snowy, mountain and road conditions.

    Seat stem position of the Lithium-Ion battery results in more balanced riding. It will feel more natural since all the weight is concentrated in the center. Lithium-Ion battery is removable and can be charged on or off the bike.

    ** Weather, battery charge level, variable conditions depending.

    500W Folding Electric Bike Specifications:

    Motor power: 500W

    Rated voltage: 48V

    Maximum speed: 20MPH

    Battery Life: 30 Miles (1 hour ride time)

    Vehicle weight: 55lbs(with battery)

    Front brake type: Disc

    Rear brake type: Disc

    Rear rack: Available

    Free Gift Cards

    Folding Electric Bicycle Packaging:

    1.Firstly, white sheet sponge wrap unitized frame.

    2.Secondly,bubble sheet wrap the unitized frame again.

    3.At last, pack products with corrugated carton.

    Warranty Of the 20 inch Folding Ebike for Adults:

    Motor: 2 years

    Battery: 18 months

    Controller,Charger and other electric parts: 1 year

    The following cases are not in the warranty:

    1. The accidents caused for the user did not use, maintain and adjust scooter in accordance with the manual.

    2. The user makes alteration. Damage caused by overhaul, and non-compliance use with regulations, resulting in an accident.

    3. User’s improper storage or failure caused by accidents.

    4.No warranty card or the card can not match the purchase receipt.

    5. The appearance damage after use is not covered within the warranty.

    6. Self demolition of damaged parts inaddition to the manual.

    7. A long time ride in the rain ordamage caused by immersion in water.

    Details – 500W Electric Bikes For Adults

    Detailed Pictures – 500W Electric Bike

    Details_01.jpgDetails_02.jpgDetails_03.jpgDetails_04.jpgDetails_05.jpgDetails_06.jpgDetails_07.jpgDetails_08.jpgDetails_09.jpgDetails_10.jpg

    About Secutronic:

    1. Professional manufacturer of electric bike / bicycle / scooter with 5 years research, development and producing experience.



    2. Our advanced technology and quality management ensure the superior quality with reasonable price.



    3. Fast delivery: usually ship out in 2-3 days for items in stock, and generally takes 1 – 2 weeks for bulk order.



    4. Easy communication and fast responsibility, warm-hearted after-sale service.

    Parameters:

    Category Electric fat tire bike
    Model S9F
    Colors White/blue, black/green, black/red
    Frame 6061 aluminum alloy foldable frame
    Front fork Aluminum alloy suspension fork
    Driving modes Pure electric(5 shifts), Electric assist(5 shifts), Pure human riding
    Battery Removable lithium-ion battery 48V 10Ah
    Range in electric mode 40 km
    Range in electric assist mode 60 km
    Charging methods Charge directly or take the battery out for charging
    Charger Local standard input 100~240V AC, output 54.6V 2A, overvoltage, overcurrent, short circuit protection
    Charging time 4-5 hours
    Motor Rear drive 48V 500W high speed, brushless, geared, hub motor
    Controller Intelligent sine wave integrated IC control chip
    Meter LCD display control instrument
    Cruise control 4 levels cruise control
    Accelerator Rotatable throttle grip/Pedal assist
    Headlight & Horn Integrated LED headlight & horn
    Protection level IP54
    Max speed 40 km/h
    Gears 7 speed
    Shifter lever Shimano SL-TX50-7R
    Rear derailleur Shimano RD-TZ500
    Cassette Shimano MF-TZ500, 14-28T, 7-speed
    Crankset Prowheel aluminum alloy, 52T
    Chain E-bike optimized, 7-speed
    Front hub Quick release aluminum alloy hub
    Rims Aluminum alloy
    Tires 20*4.0″ fat tires
    Brake levers Aluminum alloy, cut off the power to the motor when braking
    Brakes Mechanical disc brakes
    Handlebar Aluminum alloy for fat bike
    Stem Aluminum alloy
    Headset Aluminum alloy CNC
    Saddle Body geometry comfortable sponge saddle
    Seat post Aluminum alloy
    Pedals Aluminum alloy pedals
    Accessories Kickstand, fenders, tools
    Max load 150 kg
    Net weight 24 kg
    Gross weight 31 kg
    Carton size 143*30*80 cm

    Electrick Bike 500W Applications:

    Product Name EU Europe Warehouse Fat Tire Folding 500W 36V Share Electric Bike Fatbike Ebike Power E Bicycle For Adult
    Item Electric Bicycle Fat Tire Folding
    Product Electric Bike 500W
    Motor Power 500W Brushless Motor
    Delivery time 2-3 days
    Manufacturer Secutronic Technology – A professional manufacturer of advanced personal vehicles and solutions that increase your productivity and reduce costs. Secutronic is committed to improving customer satisfaction through advanced technology and a commitment to innovation, quality, value and design. With its state-of-the-art digital technology, a strong R&D department and a well-trained production team help produce the most advanced products.
    Advantage ISO9001 quality management system certification and ISO14001 environmental management system certification, Superior Quality with Competitive price; In time delivery

    Packaging
